35M Eco-friendly Camouflaged Maple Tree Bionic Tower Hot Dip Galvanized 4G 5G Wifi Long Range Communication Signal Mast

Name: 35M Eco-friendly Camouflaged Maple Tree Bionic Tower Hot Dip Galvanized 4G 5G Wifi Long Range Communication Signal Mast
Brand: Jiayao Co., Ltd.
SKU: Menara Pohon Bionik
Price: 50.00 USD
Availability: InStock

Semua produk

Menara Baja Sudut Berkaki 3
(48)

Menara Baja Angular Berkaki 4
(61)

Menara Baja Tubular Berkaki 3
(45)

Menara Monopole
(53)

Menara Kawat Guyed
(26)

Menara Penjaga
(15)

Menara Pohon Bionik
(25)

Menara Transmisi Daya
(18)

I 'm Online Chat Now

35M Eco-friendly Camouflaged Maple Tree Bionic Tower Hot Dip Galvanized 4G 5G Wifi Long Range Communication Signal Mast

Gambar besar : 35M Eco-friendly Camouflaged Maple Tree Bionic Tower Hot Dip Galvanized 4G 5G Wifi Long Range Communication Signal Mast

Detail produk:

Tempat asal:	Cina
Nama merek:	Jiayao
Sertifikasi:	ISO9001:2008 COC
Nomor model:	Menara Pohon Bionik

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	4 ton
Harga:	US$1600,1-100Tons;US$1000,>=100 Tons
Kemasan rincian:	Dikemas dalam Kotak Kayu Atau Dibungkus dengan Lembar Galvanis
Waktu pengiriman:	15-20 hari
Syarat-syarat pembayaran:	L/C, T/T
Menyediakan kemampuan:	500-800 ton per bulan

Kontak bicara sekarang

35M Eco-friendly Camouflaged Maple Tree Bionic Tower Hot Dip Galvanized 4G 5G Wifi Long Range Communication Signal Mast

Deskripsi

Bahan:	Q345b	Sertifikat:	ISO9001:2008
Nama Produk:	Menara Bionic Pohon Maple Tersamar Ramah Lingkungan	Tinggi:	10-80 m
Kecepatan angin:	1-42KM/jam	Kehidupan Pelayanan:	15-50 Tahun
Dampak Lingkungan:	Ramah Lingkungan	Estetika:	Penampilan alami dan realistis
Fitur Keamanan:	Anti korosi, anti karat, dan anti petir
Menyoroti:	Eco-friendly bionic tree tower , Galvanized 4G 5G signal mast , Long range communication tower

JIAYAO CO., LTD.

1.Specifications

Design
1. Design Code	ANSI/TIA-222-G/H/F
Structure Steel
2. Grade	Mild Steel	High Tensile Steel
	GB/T 700:Q235B, Q235C,Q235D	GB/T1591:Q355B, Q355C,Q355D
	ASTM A36	ASTM A572 Gr50
	EN10025: S235JR, S235J0,S235J2	EN10025: S355JR, S355J0,S355J2
3. Design Wind Speed	Up to 250 km/h
4. Allowable deflection	0.5 ~1.0 degree @ operational speed
5. Tension strength (Mpa)	360~510	470~630
6. Yield strength (t≤16mm) (Mpa)	355	235
7. Elongation (%)	20	24
8. Impact strength KV (J)	27(20°C)---Q235B(S235JR)	27(20°C)---Q345B(S355JR)
	27(0°C)---Q235C(S235J0)	27(0°C)---Q345C(S355J0)
	27(-20°C)---Q235D(S235J2)	27(-20°C)---Q345D(S355J2)
Bolts & Nuts
9. Grade	Grade 4.8, 6.8, 8.8
10. Standards for mechanical properties
10.1 Bolts	ISO 898-1
10.2 Nuts	ISO 898-2
10.3 Washers	ISO 6507-1
11. Standards for Dimensions
11.1 Bolts	DIN7990, DIN931, DIN933
11.2 Nuts	ISO4032, ISO4034
11.3 Washers	DIN7989, DIN127B, ISO7091
Welding
12. Method	CO2 Shielded Arc Welding & Submerged Arc Welding(SAW)
13. Standard	ISO9001:2008 COC
Marking
14. Method of marking of the members	Hydraulic Press Stamping
Galvanizing
15. Galvanization standard of steel sections	ISO 1461 or ASTM A123
16. Galvanization standard of bolts and nuts	ISO 1461 or ASTM A153

2.Product Detail

Please Click Here For More Information!!!!!!

3.Packaging & Shipping

4.Cooperation Customers

5.Certifications

6.Our Services

JIAYAO CO., LTD. is a professional telecom tower manufacturer and approved by ISO9001. We are committed to providing customers with the most optimized solutions and the best communication tower. Many products have been exported to USA, Europe and other 55 different counties.
We specialize in designing and manufacturer of angle steel tower, tube steel tower, monopole tower, pine tree tower, guyed tower and guard tower. Our departments include design, R&D, inspection, laboratory, QC, galvanization and steel tower departments. Our raw materials come from famous steel mills in China: HBIS Group, Baowu Steel Group, Shougang Group.

If you need it, we will welcome you 24 hours a day!

Design
1. Design Code	ANSI/TIA-222-G/H/F, EN 1991-1-4 & EN 1993-3-1
Structure Steel
2. Grade	Mild Steel
	GB/T 700:Q235B, Q235C,Q235D
	ASTM A36
	EN10025: S235JR, S235J0,S235J2
3. Design Wind Speed	Up to 250 km/h
4. Allowable deflection	0.5 ~1.0 degree @ operational speed
5. Tension strength (Mpa)	360~510
6. Yield strength (t≤16mm) (Mpa)	355
7. Elongation (%)	20
8. Impact strength KV (J)	27(20°C)---Q235B(S235JR)
	27(0°C)---Q235C(S235J0)
	27(-20°C)---Q235D(S235J2)
Bolts & Nuts
9. Grade	Grade 4.8, 6.8, 8.8
10. Standards for mechanical properties
10.1 Bolts	ISO 898-1
10.2 Nuts	ISO 898-2
10.3 Washers	ISO 6507-1
11. Standards for Dimensions
11.1 Bolts	DIN7990, DIN931, DIN933
11.2 Nuts	ISO4032, ISO4034
11.3 Washers	DIN7989, DIN127B, ISO7091
Welding
12. Method	CO2 Shielded Arc Welding & Submerged Arc Welding(SAW)
13. Standard	AWS D1.1
Marking
14. Method of marking of the members	Hydraulic Press Stamping
Galvanizing
15. Galvanization standard of steel sections	ISO 1461 or ASTM A123
16. Galvanization standard of bolts and nuts	ISO 1461 or ASTM A153
